Description
Dahua PFM920I-5EUN Cat5e UTP 305M Network Cable
Dahua UTP CAT5E Max.160m long distance PoE supply 99.99% Oxygen free copper. Excellent material. Environmentally friendly PVC
- Material OFC(oxygen free copper)
- Composition 1/0.45
- Wire gauge 0.45*4P±0.005mm
- Min. average thickness 0.2mm
- Diameter 0.83mm±0.03mm
- Color(4 Pairs) Orange, white/orange; green, white/green; blue, white/blue; brown, white/brown
- Material PVC
- Min. average thickness 0.5mm±0.05mm
- Diameter 4.7mm
- Max. DC resistance of single conductor 12 ?/100m
- Max. voltage range 75V
- Max. unbalance rate of line pairs’ direct current resistance 12%
- Min. insulation resistance 5000M?·km
- Max. mutual capacitance 5.6NF/100m
- Max. attenuation 22(dB/100m, 100MHz)
- N.W. 7.8kg
- Packaging dimension 360mmx360mmx220mm
- Weight (with packaging) 8.6kg
Model | DH-PFM920I-5EUN-N | |
Conductor | Material | OFC(oxygen free copper) |
Composition | 1/0.45 | |
Wire gauge | 0.45*4P±0.01mm | |
Insulation | Material | HDPE |
Min. average thickness | 0.2mm | |
Diameter | 0.83mm±0.03mm | |
Color(4 Pairs) | Orange, white/orange; green, white/green; blue, white/blue; brown, white/brown |
|
Jacket | Material | PVC |
Min. average thickness | 0.5mm±0.1mm | |
Diameter | 4.7mm±0.2 mm | |
Color | White | |
Length | 305m (1000.66ft) | |
Max. DC resistance of single conductor | 12 Ω/100m | |
Max. unbalance rate of line pairs’ direct current resistance | 12% | |
Min. insulation resistance | 5000MΩ·km | |
Max. mutual capacitance | 5.6NF/100m | |
Max. attenuation | 22(dB/100m, 100MHz) | |
General | N.W. | 7.3kg |
Packaging dimension | 360mmx360mmx210mm | |
Weight (with packaging) | 8.1kg |
